160mm 24V EC Blower Fan Single Inlet Centrifugal Blowers

Model No. S3D-24160-A7-01

Voltage Type: 24VDC

Motor Type: DC Brushless External Rotor Motor

Impeller Diameter: 160mm

Impeller Material: PA66

Housing Material: Galvanized Steel

Speed Control: 0-10VDC/PWM

Protection Type: IP42

Insulation Class: B

Operation Temperature : - 25 ℃ ~ +60 ℃

Motor Protection: Over-temperature, Over-current, Locked Protected
