Voltage Type: DC
Motor Type: BLDC External Rotor Motor
Impeller Diameter: 220mm
Impeller Material: PA Plastic + Glass Fiber
Mounting Bracket: Metal
Speed Control: 0-10VDC/PWM
Protection Type: IP44
Insulation Class: B
Operation Temperature : - 25 ℃ ~ +60 ℃
Motor Protection: Locked-Rotor Protection, Reverse Polarity Protection, Thermal Protection, Soft Start
| Model No. | Bearing System | Rated Voltage | Operating Voltage | Rated Current | Rated Power | Rated Speed | Air Flow | Air Pressure | Noise Level |
| B/S | VDC | VDC | A | W | RPM | m³/h | Pa | dBA | |
| K3D-110220-S9-00 | Ball | 110 | 88~132 | 1.6 | 175 | 3550 | 1100 | 820 | 76 |
