Voltage Type: AC
Motor Type: EC Brushless External Rotor Motor
Impeller Diameter: 190mm
Impeller Material: Plastic
Speed Control: 0-10VDC/PWM
Protection Type: IP44
Insulation Class: B
Operation Temperature : - 25 ℃ ~ +60 ℃
Motor Protection: Locked-Rotor Protection, Reverse Polarity Protection, Thermal Protection, Soft Start
| Model No. | Bearing System | Rated Voltage | Frequency | Rated Current | Rated Power | Rated Speed | Air Flow | Air Pressure | Noise Level |
| B/S | VAC | Hz | A | W | RPM | M³/H | Pa | dBA | |
| K3E-2A190-A7-01 | Ball | 220 | 50/60 | 0.73 | 95W | 3570 | 750 | 600 | 76 |
